Product characteristics
The instrument uses 128 *64 dot matrix LCD display, which can store 240 standard curves.
Instrument host has USB2.0 data export function
Advanced control system to monitor the service life of tungsten lamp in real time
GLP self-identification function, wavelength accuracy and photometric accuracy of testing instrument, and can issue detection report and power-off protection.
The instrument can carry out automatic wavelength correction, automatic wavelength setting and dark current correction.
Fully sealed structure and all optical mirrors have Si02 protective film, which can reduce the influence of external gas and environment on optical components.
Supporting System Upgrade Function
Detailed specification
1200 high performance holographic gratings per millimeter for optical systems
Wavelength range: 320-1020 NM
Spectral bandwidth: 4.0 nm (2 nm)
Wavelength accuracy: +1.0nm, minimum resolution 0.1nm
Wavelength repeatability: < 0.2 nm
Photometric accuracy: +0.4% T (0-100% T)
Photometric repeatability: <0.2%T (0-100%T)
Stability: +0.001A/h (500 nm)
Stray light: < 0.05% T (360 nm)
Display mode: 128*64 liquid crystal display
Photometric range: -0.301-3.0 A, 0-200% T 0-9999C
Working methods: A, T, C, F
Wavelength setting: automatic
Detector: Imported Silicon Light Diode
Light Source: Imported Long Life Tungsten Lamp
Keyboard: Film Digital Keyboard
